Cake Makka: work

Bemærkning

• Makka flex :work
• Range: Mixed city riding (WMTC-II): 100 km*
• Top speed: 45 km/h*

Regulatory

• Makka flex :work
• Classification: L1e-b*
• License: AM, B*

DrivetraiN

• Makka flex :work
• Peak power: 3.3 kW*
• Nominal power: 1.55 kW
• Torque (wheel): 60 Nm*
• Electric motor: Interior permanent magnet motor
• Type: Direct drive (hub motor)

Battery

• Capacity
• Standard battery: 31Ah / 1.5kWh*
• FeaturesEasily removable, can be charged when installed in bike or separately. Smart charging system. Integrated SoC indicator. Intelligent battery management system with CAN for increased safety and performance optimization.
• Voltage (nominal)48 V

Brake modes

• EBS - Electronic Braking System to regenerate the braking power into the battery and increase range

Brakes

• DiscStainless steel, 220 mm diameter
• TypeMotorcycle brake system, two piston calipers. Hand levers for both front- and rear brake.

Charging

• 0-80%
• Standard battery: 2 hours*
• Type10A external charger for standard 220V outlets.

Chassis

• Frame6061-T6 Aluminium, Extruded, Forged, CNC machined, welded and painted.
• Swingarm6061-T6 Aluminium, Extruded, Forged, CNC machined, welded and painted.

Controller

• FeaturesHigh efficiency FOC controller

Dashboard

• FeaturesTFT display with battery SoC, speedometer, odometer, ride mode selection and telltales.

Dimensions

• Fork angle25°
• Ground clearance260 mm
• Height to handle1035 mm
• Offset21.7 mm
• Seat height790 mm (seat adjustment +- 85 mm)
• Trail78.1 mm
• Wheel base1210 mm
• Width750 mm

Fenders & bodywork

• MaterialPC / ABS plastic

Front suspension

• TypeSingle crown, RWU spring fork

Handlebar

• MaterialAerospace grade 7050 aluminium
• Width695 mm

Ride modes

• Two fully configurable ride modes available for use with Makka :work. Depending on your business needs you can choose to have maximum torque and speed for efficient riding and quick deliveries, longer range settings for a long-lasting battery life for short-haul transport at limited speed and maximum reach, or more balanced settings to fit specific user needs. The configs are made through the CAKE Connect app.

Stand

• TypeCentral stand

Weight

• Battery23 kg
• Dry59 kg
• Max. permittable load245 kg (bike + battery + rider + passenger + carry-on items)

Wheels & tires

• HubsForged and CNC aluminium hubs
• Rims14" x 2.15" lightweight motorcycle rims
• Tires14" x 3.00" motorcycle tires
