Cake Aik

Mentiune

Elektrisches Lastenfahrrad: kein Füherschein erforderlich!

incl. Heck und Frontträger.

Motorleistung: 100 Nm

Reichweite: bis zu 360 km

Max. zulässige Belastung: 200 kg

Getriebe: Stufenlose Automatik

Battery

• Capacity 14.5 Ah / 750 Wh
• CellsPremium 21700 lithium cells
• FeaturesThe bike can carry up to three batteries for a top class range Possibility to use one of the extra batteries as power bank, for example powering the Dometic Box Easily removable, can be charged when installed in bike or separately
• Integrated SoC indicator. Robust and durable design for demanding condition.
• Voltage (nominal) 51.8 V (48 V system)

Brakes

• DiscStainless steel, 203 mm diameter, 2.2 mm thickness
• TypeTektro HD-E740, Hydraulic bicycle disc brakes, four piston calipers, hand lever for front and rear brake.

Charging

• 0-100% 2 hours and 15 minutes*
• 0-80% 1 hour and 30 minutes*
• TypeExternal charger for standard 220 V outlets.

Chassis

• Frame6061-T6 Aluminium, Extruded, Forged, machined, welded and painted.

Connectivity

• Telematics unit with GPS, Bluetooth and GSM compatible with Cake App Cake Fleet Management App and external API integration.

Dashboard

• FeaturesTFT display with battery SoC, speedometer, ride mode selection and telltales.

Dimensions

• Fork angle 23°
• Offset 28 mm
• Seat height 790 mm (seat adjustment +- 85 mm)
• Trail 90 mm
• Wheel base 1234 mm

Drivetrain

• Belt 143 teeth
• Electricmotor Mid drive motor
• Front sprocket 55 teeth (belt)
• Nominal power 250 W
• Torque (motor axle) 100 Nm*
• Type Mid drive motor with stepless automatic gearbox in rear wheel hub
• Rear sprocket 22 teeth (belt)

Fenders & Bodywork

• MaterialPP plastic

Handlebar

• Interface 31.8 mm (22.2 mm at grips)
• Material Aerospace grade 7050 aluminium
• Rise 220 mm
• Width 750 mm

Lock and anti-theft

• Battery lock GPS activated alarm and tracking. ? Integrated anti-theft seat clamp.

Regulatory

• Classification EN15194 pedelec*

Ride modes

• Ride mode 1Reach: When range is more important than speed
• Ride mode 2Efficiency: When range and speed are equally important
• Ride mode 3Power: When speed is more important than range
• Ride mode 4Walk assist: 6 km/h using the thumb throttle

Saddle and grips

• Ergon saddle and grips

Speed & Range

• Range1 battery up to 120 km*, 3 batteries up to 360 km*
• Top speedWith padel assist: 25 km/h*
• Without assist: as fast as you can pedal

Stand

• TypeCentral stand

Suspension

• TypeRigid

Weight

• Battery 5.2 kg
• Dry 32 kg
• Max. permittable load 200 kg (bike + battery + driver + cargo)

Wheels & Tires

• Hub frontForged and CNC milled aluminium hubs with 12 mm axle
• Hub rear Enviolo Extreme AUTOMATiQ modular axle
• RimsShining DB-X50 20" aluminum bicycle rims
• Tires20" x 3.0" fat bike bicycle tires (20" is the outer diameter of bicycle tires)
